Based in the vibrant industrial landscape of Addis Ababa, Bereket Pipes has carved a niche as a trusted manufacturer and supplier, recognized for delivering robust and reliable solutions. Our specialization in Monel Coil Tubing reflects our commitment to tackling the most demanding industrial challenges. We understand that in sectors from energy to processing, integrity is non-negotiable, which is why we focus on providing tubing that stands as a benchmark for durability and performance in Ethiopia’s growing market, ensuring our clients’ operations run with seamless efficiency and long-term confidence.
Monel’s exceptional strength stems from its unique nickel-copper composition, granting it a natural, passive resistance to corrosion that outperforms many other alloys. This material maintains remarkable mechanical integrity across a wide temperature range, offering high tensile strength and excellent ductility. It shrugs off the damaging effects of everything from saltwater and alkaline solutions to reducing chemicals, making it not just strong, but intelligently resilient. This combination means the tubing can withstand significant pressure and stress without succumbing to cracking or failure.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Coil Tubing from Bereket Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Bereket Pipes and Tubes, one of the largest suppliers of Monel Coil Tubing in Addis Ababa, Ethiopia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Coil Tubing to meet your specific requirements. Our team at Bereket Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bereketpipes.com.
Monel Coil Tubing finds extensive use in industries that require flexible and corrosion-resistant tubing solutions. In the oil & gas sector, it’s utilized for hydraulic control lines, chemical injection tubing, and downhole applications where resistance to sour gas and seawater is essential. The chemical industry depends on it for transporting acids, alkalis, and other aggressive chemicals in processing plants. In marine applications, it’s used for seawater piping, heat exchangers, and condensers that are exposed to saline environments.
